Product characteristic
-
Universal Input 90-305Vac
-
Built-in Active RFC Function, High PF. Low THD
-
The whole series adopts two-stage circuit,Output no flicker
-
Proections:short Circuit ,Over-Current, Over-Voltage, Over Temperature
-
Built-in SCP.OCP.OVP.OTP function
-
Efficiency up to 91%
-
6KV/5KV surge protection
-
Working temperature-40°C-60°C, power should be derated at 70°C
-
Built-in 3 in ldimming function,intelligent time control dimming
-
Built-in optional output constant voltage auxiliary driver (+12V)
-
Certification(UL,SAA,TUV,BIS,FCC,ENEC,CCC,ROHS,CE,CB)
-
IP67, suitable for dry, damp and wet locations
-
Aluminum housing,cooling by free air converction
-
5 years warranty
|
